Rated Input Voltage (V) 220±15%
Frequency (HZ) 50/60
Rated Input Capacity (KVA) 6.1
Rated Input Current (A) 27.8
No-load Voltage (V) 60
Range of Output Current (A) 20-140
Range of  Output Voltage (V) 20.8-25.6
Rated Duty Cycle (%) 60
Efficiency(%) 80
Power factor 0.73
Protection Class IP21
Insulation  Class F
Dimension (mm) 300*125*220
Weight (kgs) 5.2
Welding electrode diameter 1.6-3.2

New function :
1)Hot start function.
2)Anti-stick function
3)Touch start function without switch
4)Overall dormant
5)VRD function
Without the power switch,has overall dormancy function,low power consumption to 3W.
Small volume ,light weight,high efficiency and energy saving.
The automatic overheated,over-current,over voltage protection.
Can be welding low carbon steel,medium carbon steel,alloy steel and other metal materials.
